PalmVID DVR LITE DIY Hide It Yourself Hidden Camera Kit with DVR

Turn almost anything into a hidden camera with this DIY Hide-It-Yourself hidden camera kit! Includes high resolution color video camera plus a built-in DVR Micro SD card video recorder

High Quality Video
This tiny camera gives an amazing video quality for it's size. You won't believe the quality of the picture from a camera so small. The camera delivers clear full motion video in a wide range of lighting conditions. The CMOS camera in this kit is rated at 1920x1080 Video Resolution (Scroll Down to View Sample Video Below)

Hide it yourself
This camera uses a mini pinhole lens so the camera can see through a tiny hole and only the pinhole lens needs to be exposed. This means it's easy to hide the rest of the electronics inside an object or it could be concealed by placing it behind other items with a just a small hole for the lens to see through. For instance it could be placed inside a cardboard box or a plastic container or many other items with just a tiny hole for the camera lens to see through.

Remote Control Included
Lets you start/stop recording manually and access other functions wirelessly - even through walls!

Built-in DVR Video Recorder
The video is recorded internally to a removable Micro SD memory card (sold separately). Works with up to 512GB Micro SD cards. Video storage is approximately 9 per hour of video recorded.

Motion Detection Recording
Start/Stop recording manually using the remote control or use motion detection mode. In motion detection mode it will remain in standby until motion is detected, then only trigger the DVR to record when it sees movement in the view. This camera uses digital motion detection which means there is no "exposed" motion detector parts because motion recording is triggered when the camera "sees" motion in the video. When there is no motion the recording will stop until the next motion-event is detected.

Digital Playback
The video files can be viewed on almost any PC, Mac, or other devices using popular free software like Windows Media Player or Kmplayer and they can be easily edited by most video editors. Connects with the USB cable to copy/transfer the files to a PC.

BATTERY POWER SPECIAL - FREE UPGRADE TO 48-HOUR BATTERY WITH NEW FAST CHARGER- EXTRA BATTERIES AND FAST CHARGERS AVAILABLE
NEW We are including a Fast Charger to recharge this camera's battery in 3-4 hours, compared to 10-12 with the standard USB cable! Plus, our new charger features a charging indicator so you know when the battery is fully charged!

Everything you need to make your own hidden camera
NEW Longer 6.5" Flexible ribbon cable makes installing the camera easy
Simple to Setup and Use
PC and Mac Compatible
CMOS Camera
Video Resolution 1920x1080
Video Format AVI (MJPEG)
Data Transfer Interface USB 1.1 or 2.0
Memory Micro SD Card Max Size 512GB
Memory Consumption 9GB/hour
Rechargeable Battery Yes (See Battery Chart Above)
Playback Software Windows Media Player or VLC
Dimensions 2 x 1 x 0.25 Inches (approx.)

Important Notes Regarding Use and Installation:
This kit should only be purchased or used by persons that are completely familiar with the proper handling, installation, and use of circuit-board level components.
The camera ribbon cable and components of this item are very fragile.
This item may be easily damaged by impacts, electric discharges, static electricity, and short circuits caused by conductive objects or liquids coming into contact with the components.
Parts of this item will generate heat during charging and during normal operation.
This item should not be installed or used near any flammable materials or vapors
This item should not be installed or used in any enclosed area without adequate venting and/or heat sinks.
The use of incorrect power supplies, batteries, chargers, or other power sources may cause overheating and/or permanent damage to this unit.

	DIY-DVR-V2	DIY-DVR-PRO	DIY-WIFI-DVR-LITE
Camera Information
Camera Resolution	HDTV 1080p	HDTV 1080p	HDTV 1080p
Camera Low Light	Good	Very Good	Very Good
Built-in DVR Video Recorder Information
Recording Resolution	HDTV 1080p	HDTV 720p	HDTV 1080p
Frames Per Second	30FPS	24 FPS	24 FPS
Time and Date stamp	Yes	Yes	Yes
Motion Activated Recording	Yes - Basic	Yes - Advanced	Yes - Advanced
Recording Locations	Internal: Memory Card	Internal: Memory Card	Internal: Memory Card External: Phone, Tablet
Memory Size (Capacity)	Up to 512 GB (optional)	Up to 1000 GB (1 TB) (optional)	Up to 1000 GB (1 TB) (optional)
Memory Card Speed	Class 10 or Higher	Class 10 or Higher	Class 10 or Higher)
User Accessible Memory Card	Yes	Yes	Yes
HDTV Recording Rate	~ 9 GB per Hour	~ 2 GB per Hour	~ 1 GB per Hour
Field of View:	80°	90°	90°
Loop/Recycle Recording	No	Yes	Yes
Remote Control:	Yes	Yes	Remotely Controlled over App
Warranty:	12 Months	12 Months	12 Months
Live Remote Viewing, Recording, and Playback Methods
iPhone, iPad, Android Phone, Tablet	No	No	Yes - Free Advanced App
Windows PC, Laptop	Yes (Via USB)	No	Yes - Free Advanced App (with free emulator)
Video Playback	Computer	Computer	Computer, Mobile App
Internet Live View (WiFi):	No	No	Yes
Live View Methods:	USB to PC	TV or Monitor	Computer,iPhone, iPad,or Android Smart phones and Tablets
Power/Battery Information
AC/DC Wall Power Supply	Yes (included USB cord)	Yes (included AC cord)	Yes (included USB cord)
Battery Info (More Info in the columns below)	Included rechargeable battery with up to 4 hours total motion- activated recording time and standby time	Included rechargeable battery with with up to 100 Days total motion-activated standby time in PIR mode	Included rechargeable battery with up to 4 hours total motion- activated recording time and standby time
Battery Option Information: Recording time (Continuously)	Up to 2 hours with Standard Life Battery Up to 4 hours with Extra-Life Battery Up to 12 hours with Super-Life Battery	Up to 2 hours with Standard Life Battery Up to 4 hours with Extra-Life Battery Up to 12 hours with Super-Life Battery	Up to 2 hours with Standard Life Battery Up to 4 hours with Extra-Life Battery Up to 12 hours with Super-Life Battery
Battery Option Information: Recording time (Motion Activated)	Up to 4 hours with Standard Life Battery Up to 16 hours with Extra-Life Battery Up to 32 hours with Super-Life Battery	Up to 4 hours with Standard Life Battery Up to 16 hours with Extra-Life Battery Up to 32 hours with Super-Life Battery	Up to 4 hours with Standard Life Battery Up to 16 hours with Extra-Life Battery Up to 32 hours with Super-Life Battery
Battery Option Information: Recording time (PIR Motion Activated)	N/A	Up to 7 days with Standard Life Battery Up to 50 days with Extra-Life Battery Up to 100 days with Super-Life Battery	N/A
